Conducteurs multi-brins

Pour la mise en œuvre dans des installations de protection contre la foudre et de mise à la terre.

Conducteur multi-brin en aluminium

Par ex. pour une mise en œuvre d'un dispositif de capture isolé (fil tendu : DEHNiso-combi).

1 Prodotto

Art. 840050 SEIL 9 50Q AL R100M

GTIN (EAN) 4013364070141, Codice doganale (EU): 76149000, Peso lordo: 133.00 g/m, UM: 100.00 m


Immagini

Maggior informazioni


Section: 50 mm2
Structure du câble nombre x Ø conducteur: 19 x 1,8 mm
Matériau: Al

produit : DEHN
Type: SEIL 9 50Q AL R100M
Référence: 840050
ou équivalent

Certificati



Caratteristiche tecniche

Section 50 mm2
Structure du câble nombre x Ø conducteur 19 x 1,8 mm
Matériau Al
Normes NF EN 62561-2 (voir rapport de test)
Diamètre Ø extérieur 9 mm
Courant de court-circuit (AC 50 Hz/DC) (1 s ; ≤ 300 °C) 6,4 kA
Tolérance de longueur +/- 5 %
Remarque : Al ne doit pas être posé directement (sans écartement) sur, dans ou sous du crépi, du mortier ou du béton ni dans la terre.

Prodotto 840050 è stato aggiunto al blocco note.

Prodotto 840050 è stato aggiunto al carrello.

Apri Web-Shop

Conducteur multi-brin en acier

2 Prodotti

Art. 801059 SEIL 11.5 STGALZN R50M

GTIN (EAN) 4013364523173, Peso lordo: 660.00 g/m, UM: 50.00 m


Immagini

Maggior informazioni


Section: 75 mm2
Structure du câble nombre x Ø conducteur: 19 x 2,3 mm
Matériau: St/gal Zn

produit : DEHN
Type: SEIL 11.5 STGALZN R50M
Référence: 801059
ou équivalent



Caratteristiche tecniche

Section 75 mm2
Structure du câble nombre x Ø conducteur 19 x 2,3 mm
Matériau St/gal Zn
Diamètre Ø extérieur 11,5 mm
Tolérance de longueur +/- 5 %

Prodotto 801059 è stato aggiunto al blocco note.

Prodotto 801059 è stato aggiunto al carrello.

Apri Web-Shop

Art. 801058 SEIL 11.5 STGALZN R20M

GTIN (EAN) 4013364523166, Codice doganale (EU): 73121081, Peso lordo: 660.00 g/m, UM: 20.00 m


Immagini

Maggior informazioni


Section: 75 mm2
Structure du câble nombre x Ø conducteur: 19 x 2,3 mm
Matériau: St/gal Zn

produit : DEHN
Type: SEIL 11.5 STGALZN R20M
Référence: 801058
ou équivalent



Caratteristiche tecniche

Section 75 mm2
Structure du câble nombre x Ø conducteur 19 x 2,3 mm
Matériau St/gal Zn
Diamètre Ø extérieur 11,5 mm
Tolérance de longueur +/- 5 %

Prodotto 801058 è stato aggiunto al blocco note.

Prodotto 801058 è stato aggiunto al carrello.

Apri Web-Shop

Conducteur multi-brin en acier inoxydable

Par ex. pour l'équilibrage de potentiel.

2 Prodotti

Art. 850008 SEIL 8 V4A R100M

GTIN (EAN) 4013364129627, Codice doganale (EU): 73121020, Peso lordo: 235.00 g/m, UM: 100.00 m


Immagini

Maggior informazioni


Section: 27 mm2
Structure du câble nombre x Ø conducteur: [7x] 19 x env. 0,59 mm
Matériau: INOX (V4A)
Matériau n°: 1.4571/1.4404

produit : DEHN
Type: SEIL 8 V4A R100M
Référence: 850008
ou équivalent

Certificati



Caratteristiche tecniche

Section 27 mm2
Structure du câble nombre x Ø conducteur [7x] 19 x env. 0,59 mm
Matériau INOX (V4A)
Matériau n° 1.4571/1.4404
Diamètre Ø extérieur 8 mm
Courant de court-circuit (AC 50 Hz/DC) (1 s ; ≤ 300 °C) 1 kA
Tolérance de longueur +/- 5 %

Prodotto 850008 è stato aggiunto al blocco note.

Prodotto 850008 è stato aggiunto al carrello.

Apri Web-Shop

Art. 850010 SEIL 10 V4A R100M

GTIN (EAN) 4013364129634, Codice doganale (EU): 73121020, Peso lordo: 395.00 g/m, UM: 100.00 m


Immagini

Maggior informazioni


Section: 42 mm2
Structure du câble nombre x Ø conducteur: [7x] 19 x env. 0,68 mm
Matériau: INOX (V4A)
Matériau n°: 1.4571/1.4404

produit : DEHN
Type: SEIL 10 V4A R100M
Référence: 850010
ou équivalent

Certificati



Caratteristiche tecniche

Section 42 mm2
Structure du câble nombre x Ø conducteur [7x] 19 x env. 0,68 mm
Matériau INOX (V4A)
Matériau n° 1.4571/1.4404
Diamètre Ø extérieur 10 mm
Courant de court-circuit (AC 50 Hz/DC) (1 s ; ≤ 300 °C) 1,5 kA
Tolérance de longueur +/- 5 %

Prodotto 850010 è stato aggiunto al blocco note.

Prodotto 850010 è stato aggiunto al carrello.

Apri Web-Shop

Conducteur multi-brin en cuivre

5 Prodotti

Art. 832739 SEIL 9 50Q CU R50M

GTIN (EAN) 4013364018907, Codice doganale (EU): 74130000, Peso lordo: 438.00 g/m, UM: 50.00 m


Immagini

Maggior informazioni


Section: 50 mm2
Structure du câble nombre x Ø conducteur: 19 x 1,8 mm
Matériau: Cu

produit : DEHN
Type: SEIL 9 50Q CU R50M
Référence: 832739
ou équivalent

Certificati



Caratteristiche tecniche

Section 50 mm2
Structure du câble nombre x Ø conducteur 19 x 1,8 mm
Matériau Cu
Normes NF EN 62561-2 (voir rapport de test)
Diamètre Ø extérieur 9 mm
Courant de court-circuit (AC 50 Hz/DC) (1 s ; ≤ 300 °C) 9,7 kA
Tolérance de longueur +/- 5 %

Prodotto 832739 è stato aggiunto al blocco note.

Prodotto 832739 è stato aggiunto al carrello.

Apri Web-Shop

Art. 832740 SEIL 9 50Q CU R100M

GTIN (EAN) 4013364093454, Codice doganale (EU): 74130000, Peso lordo: 438.00 g/m, UM: 100.00 m


Immagini

Maggior informazioni


Section: 50 mm2
Structure du câble nombre x Ø conducteur: 19 x 1,8 mm
Matériau: Cu

produit : DEHN
Type: SEIL 9 50Q CU R100M
Référence: 832740
ou équivalent

Certificati



Caratteristiche tecniche

Section 50 mm2
Structure du câble nombre x Ø conducteur 19 x 1,8 mm
Matériau Cu
Normes NF EN 62561-2 (voir rapport de test)
Diamètre Ø extérieur 9 mm
Courant de court-circuit (AC 50 Hz/DC) (1 s ; ≤ 300 °C) 9,7 kA
Tolérance de longueur +/- 5 %

Prodotto 832740 è stato aggiunto al blocco note.

Prodotto 832740 è stato aggiunto al carrello.

Apri Web-Shop

Art. 832192 SEIL 10.5 70Q CU R50M

GTIN (EAN) 4013364018914, Codice doganale (EU): 74130000, Peso lordo: 597.00 g/m, UM: 50.00 m

Predecessore

Immagini

Maggior informazioni


Section: 70 mm2
Structure du câble nombre x Ø conducteur: 19 x 2,1 mm
Matériau: Cu

produit : DEHN
Type: SEIL 10.5 70Q CU R50M
Référence: 832192
ou équivalent

Certificati



Caratteristiche tecniche

Section 70 mm2
Structure du câble nombre x Ø conducteur 19 x 2,1 mm
Matériau Cu
Normes NF EN 62561-2 (voir rapport de test)
Diamètre Ø extérieur 10,5 mm
Courant de court-circuit (AC 50 Hz/DC) (1 s ; ≤ 300 °C) 13,6 kA
Tolérance de longueur +/- 5 %

Prodotto 832192 è stato aggiunto al blocco note.

Prodotto 832192 è stato aggiunto al carrello.

Apri Web-Shop

Art. 832095 SEIL 12.5 95Q CU R50M

GTIN (EAN) 4013364048324, Codice doganale (EU): 74130000, Peso lordo: 845.00 g/m, UM: 50.00 m


Immagini

Maggior informazioni


Section: 95 mm2
Structure du câble nombre x Ø conducteur: 19 x 2,5 mm
Matériau: Cu

produit : DEHN
Type: SEIL 12.5 95Q CU R50M
Référence: 832095
ou équivalent

Certificati



Caratteristiche tecniche

Section 95 mm2
Structure du câble nombre x Ø conducteur 19 x 2,5 mm
Matériau Cu
Normes NF EN 62561-2 (voir rapport de test)
Diamètre Ø extérieur 12,5 mm
Courant de court-circuit (AC 50 Hz/DC) (1 s ; ≤ 300 °C) 18,5 kA
Tolérance de longueur +/- 5 %

Prodotto 832095 è stato aggiunto al blocco note.

Prodotto 832095 è stato aggiunto al carrello.

Apri Web-Shop

Art. 832120 SEIL 14.5 120Q CU R25M

GTIN (EAN) 4013364129610, Codice doganale (EU): 74130000, Peso lordo: 1.03 kg/m, UM: 25.00 m


Immagini

Maggior informazioni


Section: 120 mm2
Structure du câble nombre x Ø conducteur: 19 x 2,8 mm
Matériau: Cu

produit : DEHN
Type: SEIL 14.5 120Q CU R25M
Référence: 832120
ou équivalent

Certificati



Caratteristiche tecniche

Section 120 mm2
Structure du câble nombre x Ø conducteur 19 x 2,8 mm
Matériau Cu
Normes NF EN 62561-2 (voir rapport de test)
Diamètre Ø extérieur 14,5 mm
Courant de court-circuit (AC 50 Hz/DC) (1 s ; ≤ 300 °C) 23,4 kA
Tolérance de longueur +/- 5 %

Prodotto 832120 è stato aggiunto al blocco note.

Prodotto 832120 è stato aggiunto al carrello.

Apri Web-Shop

Conducteur multi-brin en cuivre étamé

5 Prodotti

Art. 832838 SEIL 7.5 CUGALSN 35Q R100M

GTIN (EAN) 4013364335776, Codice doganale (EU): 74130000, Peso lordo: 334.00 g/m, UM: 100.00 m


Immagini

Maggior informazioni

Conducteur multi-brins en cuivre étamé 35mm² Cu/gal Sn
Conducteurs multi-brins pour la mise en oeuvre dans des installations de mise à la terre et de protection contre la foudre.
Section: 35 mm2
Structure du câble nombre x Ø conducteur: 7 x 2,5 mm
Matériau: Cu/gal Sn

produit : DEHN
Type: SEIL 7.5 CUGALSN 35Q R100M
Référence: 832838
ou équivalent

Certificati



Caratteristiche tecniche

Section 35 mm2
Structure du câble nombre x Ø conducteur 7 x 2,5 mm
Matériau Cu /gal Sn
Diamètre Ø extérieur 7,5 mm
Courant de court-circuit (AC 50 Hz/DC) (1 s ; ≤ 150 °C) 5 kA
Tolérance de longueur +/- 5 %

Prodotto 832838 è stato aggiunto al blocco note.

Prodotto 832838 è stato aggiunto al carrello.

Apri Web-Shop

Art. 832839 SEIL 9 50Q CUGALSN R100M

GTIN (EAN) 4013364093164, Codice doganale (EU): 74130000, Peso lordo: 438.00 g/m, UM: 100.00 m


Immagini

Maggior informazioni

Conducteur mulit-brins en cuivre étamé 50mm² Cu/gal Sn
Conducteurs multi-brins pour la mise en oeuvre dans des installations de mise à la terre et de protection contre la foudre.
Section: 50 mm2
Structure du câble nombre x Ø conducteur: 19 x 1,8 mm
Matériau: Cu/gal Sn

produit : DEHN
Type: SEIL 9 50Q CUGALSN R100M
Référence: 832839
ou équivalent

Certificati



Caratteristiche tecniche

Section 50 mm2
Structure du câble nombre x Ø conducteur 19 x 1,8 mm
Matériau Cu /gal Sn
Normes NF EN 62561-2 (voir rapport de test)
Diamètre Ø extérieur 9 mm
Courant de court-circuit (AC 50 Hz/DC) (1 s ; ≤ 150 °C) 7,2 kA
Tolérance de longueur +/- 5 %

Prodotto 832839 è stato aggiunto al blocco note.

Prodotto 832839 è stato aggiunto al carrello.

Apri Web-Shop

Art. 832202 SEIL 10.5 70Q CUGALSN R50M

GTIN (EAN) 4013364081048, Codice doganale (EU): 74130000, Peso lordo: 597.00 g/m, UM: 50.00 m

Predecessore

Immagini

Maggior informazioni


Section: 70 mm2
Structure du câble nombre x Ø conducteur: 19 x 2,1 mm
Matériau: Cu/gal Sn

produit : DEHN
Type: SEIL 10.5 70Q CUGALSN R50M
Référence: 832202
ou équivalent

Certificati



Caratteristiche tecniche

Section 70 mm2
Structure du câble nombre x Ø conducteur 19 x 2,1 mm
Matériau Cu /gal Sn
Normes NF EN 62561-2 (voir rapport de test)
Diamètre Ø extérieur 10,5 mm
Courant de court-circuit (AC 50 Hz/DC) (1 s ; ≤ 150 °C) 10,1 kA
Tolérance de longueur +/- 5 %

Prodotto 832202 è stato aggiunto al blocco note.

Prodotto 832202 è stato aggiunto al carrello.

Apri Web-Shop

Art. 832295 SEIL 12.5 95Q CUGALSN R50M

GTIN (EAN) 4013364093447, Codice doganale (EU): 74130000, Peso lordo: 845.00 g/m, UM: 50.00 m


Immagini

Maggior informazioni


Section: 95 mm2
Structure du câble nombre x Ø conducteur: 19 x 2,5 mm
Matériau: Cu/gal Sn

produit : DEHN
Type: SEIL 12.5 95Q CUGALSN R50M
Référence: 832295
ou équivalent

Certificati



Caratteristiche tecniche

Section 95 mm2
Structure du câble nombre x Ø conducteur 19 x 2,5 mm
Matériau Cu /gal Sn
Normes NF EN 62561-2 (voir rapport de test)
Diamètre Ø extérieur 12,5 mm
Courant de court-circuit (AC 50 Hz/DC) (1 s ; ≤ 150 °C) 13,7 kA
Tolérance de longueur +/- 5 %

Prodotto 832295 è stato aggiunto al blocco note.

Prodotto 832295 è stato aggiunto al carrello.

Apri Web-Shop

Art. 832320 SEIL 14.5 120Q CUGALSN R25M

GTIN (EAN) 4013364129641, Codice doganale (EU): 74130000, Peso lordo: 1.03 kg/m, UM: 25.00 m


Immagini

Maggior informazioni


Section: 120 mm2
Structure du câble nombre x Ø conducteur: 19 x 2,8 mm
Matériau: Cu/gal Sn

produit : DEHN
Type: SEIL 14.5 120Q CUGALSN R25M
Référence: 832320
ou équivalent

Certificati



Caratteristiche tecniche

Section 120 mm2
Structure du câble nombre x Ø conducteur 19 x 2,8 mm
Matériau Cu /gal Sn
Normes NF EN 62561-2 (voir rapport de test)
Diamètre Ø extérieur 14,5 mm
Courant de court-circuit (AC 50 Hz/DC) (1 s ; ≤ 150 °C) 17,4 kA
Tolérance de longueur +/- 5 %

Prodotto 832320 è stato aggiunto al blocco note.

Prodotto 832320 è stato aggiunto al carrello.

Apri Web-Shop

back to top
